Use of the iGrade StarFire GNSS antenna in any other manner is neither permitted nor supported and can degrade desired performance of the paired receiver.

The StarFire 3000 Receiver must remain mounted to the same implement as the iGrade antenna being utilized. The iGrade antenna is only compatible with StarFire 3000 Receivers and is only intended for use on the implement receiver utilizing iGrade or other earthmoving applications.

Implement receivers in horizontal-accuracy-only applications.

The iGrade antenna is only necessary for iGrade users demanding the highest possible vertical accuracy for their applications and should not be installed on the following: It is compatible with global positioning system (GPS) offering L1, L2, and L5 satellite signals and Russian satellite constellation (GLONASS) offering G1 and G2 satellite signals, as well as the StarFire network (L-band), making it an excellent enhancement to the StarFire 3000 Receiver. The iGrade antenna resists signal interference, allowing for the rejection of error that can typically be caused by multipath effects. Vertical accuracy can be impacted by signal interference that the StarFire 3000 Receiver is susceptible to, such as multipath. The iGrade StarFire GNSS antenna (iGrade antenna) facilitates enhanced performance of the implement’s StarFire 3000 Receiver when utilized for iGrade that requires maximum vertical precision. The vertical accuracy performance of the StarFire 6000 with internal antenna for iGrade applications is similar to that of the StarFire 3000 with external iGrade antenna. The StarFire 6000 Receiver is not currently compatible with external antennas.

#Igrade and water pro plus manual

Adaptor harness schematics are available in the Technical Manual to create a wiring adaptor from UCC2 Application Controller 1100 to the existing harnessing from a UCC1 system. Harness optionsĮnsure UCC2 main harness PFA11888 is used with the UCC2 Application Controller and replaces the existing harness connection. UCC2 Application Controller 1100 (serial number PCXL01C201000+) is not compatible with original UCC1 Application Controller 1100 harnessing. Plugging the UCC2 controller into UCC1 harnessing will cause CAN bus issues due to no terminator in the circuit. The John Deere Application Controller 1100 is required for iGrade activation. IGrade requires the receiver to have an RTK signal level. iGrade does not support WAAS, EGNOS, SF1, SF2, or SF3 signal levels. Compatible with integrated AutoTrac, AutoTrac Controller, and AutoTrac Universal.*When equipped with optional electronic SCVs.Any SCVs can be used and an option connector is not used. Compatible using John Deere proprietary SCV type.Running with John Deere legacy requires using SCVs 1 or 3 and connecting the UCC harness to the option connector at the rear of the tractor cab. Compatible using John Deere legacy SCV.Compatible using external selective control valve (SCV) and external SCV switch.

#Igrade and water pro plus series

Non-John Deere tractors, 60 Series and older tractors, 5XXX, 6X00, 6X10, 6X30, 7X00, 7X10, and Small- Frame 7X20/7X30 Tractors.IGrade is approved for the following platforms: NOTE: See this link for further StarFire 6000 compatibility information. If a StarFire 3000 is used on the machine, a StarFire 3000 must be used on the implement if utilizing a second receiver for specific operation. It requires a vehicle global positioning system (GPS) only the receiver must have an SF2 or greater signal level.

#Igrade and water pro plus software

Surface Water Pro™ Plus software on GreenSand GreenSDisplays only.StarFire™ 3000 Receiver or StarFire 6000 Receiver.4200 CommandCenter Display/4240 Universal Display.

4600 CommandCenter™ Display/4640 Universal Display.

An iGrade™ leveling system activation works with many of the different John Deere Precision Ag Technology components that producers may already own such as:
